Foil Front Wing Curve V2

For whom ?

In wing foiling, you know how to take off and stabilize the flight and you want a front wing that will help you work on maneuvers and catch your first waves. In surf foiling, same thing, you know how to take off on whitewater and surf towards the beach but you want to start surfing parallel to the wave and do a few maneuvers.

If you recognize yourself in the previous paragraph, the Curve is made for you, and it will accompany you for a long time in your progression.

If you think you have more experience, you can still consider the Curve because it is super fun and hassle-free, even in soft waves. You can for instance go down one size for more reactivity!

What for ?

Carve and make the most of the waves, whether they have power or not, this front wing provides lift, grip and rail to rail. To sum up, this wing is for progressing or having fun and making curves like on a shortboard.
Its ability to turn at low speed, coupled with its early lift make it a wing of choice in situations where it may be difficult to generate enough speed.

In detail for each sport:

• In surf foiling, you have a beginner/intermediate level and you can link maneuvers and pump to connect.
• In downwinders you fly easily and endlessly without the need for huge bumps. The front wing glides and takes off again very easily. You can take advantage of each small section of bump with its maneuverability.
• In winging, the small sizes are fantastic for taking off in no wind. You can size almost 200cm² less than usual. You have an incredible rail to rail that allows you to surf all types of waves. On the other side of the spectrum, associated with a Cruzader, you will pulverize your low range. It’s just amazing how early it flies. And the speed remains top-ranked.

Which shape of the Curve to go for? Curve or Curve H?

The Curve and Curve H program remains common, an accessible glide with great maneuverability at all speeds. Choosing between Curve and Curve H does not change your practice, but refines it.

These two ranges have been designed to complement each other perfectly. The surface increases every 100cm². The difference in thickness is 1mm from one size to another. You can thus build a quiver composed only of Curve or Curve H, or build a quiver mixing these two front wings according to your practice.

If we had to compare the Curve and Curve H ranges to a surfboard, it would correspond to a mid length. With all the ease, versatility, glide, and above all the performance that we know from them thanks to an efficient shape.

A Curve would compare to a 6’5 mid length with a twin fin set-up as it’s easy, versatile, ultra maneuverable, fun in many conditions and combining speed and acceleration. A Curve H would rather compare to a 7′ mid length on a single fin set-up because it’s very easy, versatile and offers unbridled speed. The Curve H is easy to access but at the same time great for its piloting finesse.

Regarding their abilities in carves, the Curve has the edge for tight turns, the Curve H for its masterful glide.

The Curve will have greater stability/grip thanks to a more important dihedral; the Curve H will be a little more unbridled.

The aspect ratio of the Curve H is more important, but without being in the extreme ranges that can go up to 10 which are much less manageable. We enjoy the exceptional glide of high aspect wings, while maintaining excellent maneuverability.

Curve H tips are thinner and have less surface area. This keeps excellent maneuverability for wings of this size. The camber is less important, in order to maintain an excellent rail to rail despite the high ratio.

Pumping on the Curve H is a little more technical, but will be more efficient thanks to its higher ratio and shorter chord length. Perfect for slightly more experienced levels. In wing foiling, the Curve H will require a little more speed on takeoff than the Curve, but it is still very accessible.

You can easily build a quiver of 2 or 3 wings within this range, and by mixing Curves and Curves H according to your use.

Some examples to choose between Curve and Curve H

• I come from a beginner front wing and I want to favor ease of take-off in wing foiling, especially in the light wind conditions, I choose the Curve.
• My priority is to carve, whether in wing foiling or surf foiling, I take the Curve.
• I already have an advanced level in surf foiling, and my priority is pumping to connect as much as possible, I choose the Curve H.
• I have an intermediate level in wing foiling, and I still work on my jibes, I choose the Curve.
• I’m into surf foiling and also dock starting on flat days, I choose the Curve H.
• I have a good level in wing foiling and my priority is downwind, I choose the Curve H.
• Bigger riders will probably prefer the Curve with their moderate wingspan.
• I have a good level in wing foiling and I have a medium/large size, I can make the Curve MH my everyday wing.

What size ?

The Curve wings can fit riders of all sizes.

The S has a wingspan of 74 cm, 800 cm², 1.6 cm thick for a volume of 0.66L.

• In surf foiling, it is a small wing which will suit light riders with a very good technical level. It can also be used in tow-in in moderate waves.
• For winging, it will suit light riders with a very good technical level or in strong winds.
• In kite foiling, it is a reference wing, it takes off easily, excels in carving, while having an excellent top speed. It will be perfect for a confirmed kite foiler who is looking for a wing to go out in all conditions.

The M has a wingspan of 83 cm, 1000 cm², 1.8 cm thick for a volume of 0.93 L.

• In surf foiling, it is a wing that will be perfect for light riders, or for larger riders of good level in powerful waves.
• For winging, it is a relatively small wing, but which will suit light riders with a good level, or larger riders with a good level who will take it out in strong wind and wave conditions.
• In kite foiling: This is a large kite for beginners who want to sail at low speed under canopy. It should be reserved for those weighing over 85kg.

The L has a wingspan of 90 cm, 1200 cm², 1.9 cm thick for a volume of 1.21L.

• In surf foil, it will be a central front wing in the quiver of a good surf foiler.
• For winging, the lightweights with a good level will make it their light wind front wing. It is also a key wing for downwinders.
• In kite foiling: to forget, it’s too big.

The XL has a wingspan of 98 cm, 1400 cm², 2.1 cm thick for a volume of 1.54 L.

• In surf foiling, it will be a perfect wing for a good surfer in small surf conditions, and a central front wing for large riders of a good level.
• For winging, the big guys will make it their downwind front wing.
• In kite foiling: to forget, it’s too big.

The XXL has a wingspan of 104 cm, 1600 cm², 2.2 cm thick for a volume of 1.86 L.

• In surf foiling, it is a very large front wing which will be perfect for heavy riders, it is a perfect wing for dock starts too.
• In wing foiling, it is a very good light wind wing which will be perfect for heavy riders, ideal for downwinders in light conditions.
• In kite foiling: to forget, it’s too big.

General: a bigger front wing will be used in low ranges, in soft conditions. And conversely a smaller front wing in stronger conditions. What you need to remember is that the choice of your wing depends on your size, which requires lift, and your average speed, which generates lift.

Understand our foil range

Which stab ?

We recommend using Curve stabs with Curve wings. Do not use stabs that have very limited surface.

If you want to release the tail a bit, for a snappier feel, you can equip a Fluid H stab with a Curve.

This table allows you to easily identify which stab for which front wing, or which stab for a quiver of several Curve front wings.

Quiver partner ?

With a Curve, an aluminum mast or acarbon V2 are sufficient, if you really are comfortable in curves, an HM carbon mast will allow you to transmit 100% of the forces to the front wing. The gain in stiffness and dynamism is incredible.

In surf foiling, you can use any board from our range with the Curve, but to be more maneuverable, a performance board like the Matata or theLethal will be perfect.

Ditto in wing foiling, it can adapt to everything but it maneuvers better on a shorter board.

Positioning of the foil ?

For the GONG foils, place the top plate at the rear third of the US rails for surf, SUP and kite. Place it in the middle of the US rails when using it with a wing foil.

The more you move it forward, the more it makes the board pitch up. The further you move it backwards, the more the nose of the board dives.

Be careful not to move it too far forward. We often tend to forget to use the back foot, especially when we have a kite foil background. However, moving the foil back a little forces you to put more weight on the back foot and gives a more harmonious attitude and reduces effort.

Screws not included, your needs are:

Our front wing – fuselage connection works with three screws for the majority of sizes:

• 1 torx screw T30 M6X 20 MM (front screw)
• 1 torx screw T30 M6X 16 MM (rear screw)
• 1 torx screw T30 M6X 12 MM (top locking screw)
